Input Voltage ： AC 100-240V
Input Voltage Frequency ： 50/60Hz
Output Voltage ： DC 12V +/-5%
Total Output Current ： 5A
Total Outputs ： 4
Fuse Type ： PTC (Resetable)
Fuse Rating ： 2A
Features ：
General protection: each output has independent PTC fuse and LED indicator, when problem occurs, only affect the independent output, other outputs still working.
Circuit short protection: when short condition occurs, independent PTC fuse will open the circuit,when condition removed, PTC fuse will automatically back to close.
High voltage protection: when high voltage occurs, the surge protection will be hit through to protect the connected device.
Over Current protection: when over current occurs, the power supply will automatically switch to self-protection status, when condition removed, then switch back to normal.
Application ： CCTV Camera, PTZ, IR Illuminator, Video Processor， Access Control , etc.
Packing Dimension ：140×61×187mm
Net Weight ： 2.1Kg
